Boost Business Productivity

  • Up to 65/32 ppm in black & white for A4/A3
  • Paper formats: A6-SRA3, custom formats and banner format up to 1.2 metres length
  • 9-inch colour touch panel with multi-touch support and dedicated mobile touch area provides more convenience and flexibility for today's work style
  • Reduced environmental impact thanks to state-of-the-art technology that ensures competitively low energy consumption – which saves both energy and money
  • Highest data security with various security functionalities that reduce the risk of data loss and keep confidential data safe
MAIN SPECIFICATIONS
Model 658e 558e 458e
System Memory 4 GB
System Hard Disk 250 GB Standard
Interface 10-BASE-T/100-BASE-TX/1,000-BASE-T Ethernet, USB 2.0
Network Protocols TCP/IP (IPv4/IPv6), SMB, LPD, IPP, SNMP, HTTP, HTTPS
Frame Types Ethernet 802.2, Ethernet 802.3, Ethernet II, Ethernet SNAP
Automatic Document Feeder (Optional) Up to 300 originals, A6-A3, 35-210g/m2
Printable Paper Size A6-SRA3
Custom paper sizes: Banner paper max. 1,200 x 297mm
Printable Paper Weight 52-300gsm
Paper Input Capacity Standard: 1,150 sheets
Max: 6,650 sheets
Tray 1 Input 500 sheets, A5-A3, 52-256gsm
Tray 2 Input 500 sheets, A5-SRA3, 52-256gsm
Tray 3 Input
PC-115 (Optional)
500 sheets, A5-A3, 52-256gsm
Tray 4 Input
PC-215 (Optional)
2 x 500 sheets, A5-A3, 52-256gsm
Paper Feed Cabinet
PC-415 (Optional)
2,500 sheets, A4, 52-256gsm
Large Capacity Tray
LU-207 (Optional)
2,500 sheets, A4/Letter-SRA3/Ledger, 52-256gsm
Large Capacity Tray
LU-302 (Optional)
3,000 sheets, A4/Letter, 52-256gsm
Manual Bypass 150 sheets, A5-SRA3
Custom paper sizes: Banner: 60-300gsm
Automatic Duplexing A5-SRA3, 52-256gsm
Finishing Modes (Optional) Group, sort, staple, punch, output tray, booklet, center-fold, letter-fold, Z-fold
Power Consumption 220-240 V, 50/60 Hz
10A 9A 9A
2.10kWh 2.00kWh 1.95kWh
System Dimension
(W x D x H)
615 x 685 x 961mm
System Weight Approx. 96kg
PRINTER SPECIFICATIONS
Model 658e 558e 458e
Print Resolution 1,800 (equivalent) x 600 dpi, 1,200 x 1,200 dpi
Print Speed (A4) Up to 65 ppm Up to 55 ppm Up to 45 ppm
Page Description Language PostScript 3 (ver. 3016) Emulation; PCL 6 (XL Version 3.0) Emulation;
PCL5e/c Emulation; XPS
Operating System Supported Windows 7 (32/64), Windows 8.1 (32/64), Windows 10 (32/64),
Windows Server 2008 (32/64), Windows Server 2008 R2,
Windows Server 2012, Windows Server 2012 R2, Windows Server 2016,
Macintosh OS X 10.8 or later, Linux, Unix, Citrix
Printer Fonts 80 PCL; 137 PostScript 3 Emulation
Mobile Printing AirPrint (iOS), Mopria (Android), Google Cloud Print (optional),
Wi-Fi Direct (optional), Konica Minolta Print Service (Android),
Konica Minolta Mobile Print (iOS, Android, Windows 10 Mobile)
COPIER SPECIFICATIONS
Model 658e 558e 458e
Copying Process Electrostatic laser copy, intermediate
Toner Technology Simitri® HD polymerised toner
Copy Speed (A4) Up to 65 ppm Up to 55 ppm Up to 45 ppm
First Copy Out Time 3.0 secs 3.5 secs 4.0 secs
Warm-Up Time 22 secs or less 22 secs or less 25 secs or less
Copy Resolution 600 x 600 dpi
Gradation 256 gradations
Multiple Copy 1 – 9,999
Original Format A6S, B6S, A5-SRA3
Magnification 25 – 400% in 0.1% steps; Auto-zooming
SCANNER SPECIFICATIONS
Model 658e 558e 458e
Scan Speed Mono 1-sided original: 80 ipm @ 600 dpi, 120 ipm @ 300 dpi
2-sided original: 160 ipm @ 600 dpi 240 ipm @ 300 dpi
Colour 1-sided original: 75 ipm @ 600 dpi, 120 ipm @ 300 dpi
2-sided original: 150 ipm @ 600 dpi 240 ipm @ 300 dpi
Scan Resolution Max: 600 x 600 dpi
Scan Modes Scan to Email, Scan to PC (SMB), Scan to FTP, Scan to WebDAV, Scan to BOX (HDD), Scan to WSD (Web Service), Scan to DPWS (Device Profile for Web Service), Scan to USB memory, Network TWAIN scan
File Formats JPEG, TIFF, PDF, PDF/A-1a, PDF/A-1b, compact PDF, encrypted PDF and searchable PDF, XPS, compact XPS, OOXML (pptx, odcx, xlsx), Linearized PDF
Scan Destinations 2,100 (single + group); LDAP, PSDA support
FAX SPECIFICATIONS (OPTIONAL)
Model 658e 558e 458e
Fax Standard Super G3
Fax Transmission Analogue; i-Fax; Colour i-Fax; IP-Fax
Fax Resolution Up to 600 x 600 dpi (ultra-fine)
Fax Compression MH; MR; MMR; JBIG
Fax Modem Up to 33.6 Kbps
Fax Destinations 2,100 (single + group)
