Enhance Business Productivity
- Up to 36 ppm Output
- High-speed two-sided colour scanning at 160 ipm with Dual Scan Document Feeder
- Achieve higher productivity & swift output monochrome document at high resolution
- Securely handling confidential business data and flexibility in high volume finishing with advanced solutions
- Professional and quality production of business document has never been easier
- Intuitively taking advantage of feature-rich capabilities
| MAIN SPECIFICATIONS | |||||
|---|---|---|---|---|---|
| Model | 368e | 308e | |||
| System Memory | 2 GB Standard / 4 GB Maximum |
||||
| System Hard Disk | 250 GB Standard | ||||
| Interface | 10-BASE-T/100-BASE-TX/1,000-BASE-T Ethernet, USB 2.0 Wi-Fi 802.11 a/b/g/n/ac (optional) |
||||
| Network Protocols | TCP/IP (IPv4/IPv6), NetBEUI, SMB, LPD, IPP, SNMP, HTTP | ||||
| Frame Types | Ethernet 802.2, Ethernet 802.3, Ethernet II, Ethernet SNAP | ||||
| Automatic Document Feeder (Optional) |
Up to 100 originals, A6-A3, 35-163g/m2 | ||||
| Printable Paper Size | A6-SRA3 Custom Paper Sizes: Banner paper max: 297 x 1,200mm |
||||
| Printable Paper Weight | 52-300gsm | ||||
| Paper Input Capacity | Standard: 1,150 sheets Max: 6,650 sheets |
||||
| Tray 1 Input | 500 sheets, A5-A3, 52-256gsm | ||||
| Tray 2 Input | 500 sheets, A5-SRA3, 52-256gsm | ||||
| Tray 3 PC-110 (Optional) | 500 sheets, A5-A3, 52-256gsm | ||||
| Tray 4 PC-210 (Optional) | 2 x 500 sheets, A5-A3, 52-256gsm | ||||
| Paper Feed Cabinet PC-410 (Optional) | 2,500 sheets, A4, 52-256gsm | ||||
| Large Capacity Tray LU-302 (Optional) | 3,000 sheets, A4/Letter, 52-256gsm | ||||
| Manual Bypass | 150 sheets, A5-SRA3 Custom Paper Sizes: Banner: 60-300gsm |
||||
| Automatic Duplexing | A5-SRA3, 52-256gsm | ||||
| Finishing Modes (Optional) | Group, sort, staple, punch, output tray, booklet, center-fold, letter-fold, Z-fold | ||||
| Power Consumption | [220-240 V, 8A, 50/60 Hz] less than 1.58 kW (system) | ||||
| System Dimension (W x D x H) |
615 x 685 x 779mm | ||||
| System Weight | Approx. 76 kg | ||||
| PRINTER SPECIFICATIONS | |||||
| Model | 368e | 308e | |||
| Print Resolution | 1,800 (equivalent) x 600 dpi, 1,200 x 1,200 dpi | ||||
| Print Speed (A4) | Up to 36 ppm | Up to 30 ppm | |||
| Print Speed (A3) | Up to 18 ppm | Up to 15 ppm | |||
| Page Description Language | PostScript 3 (3016) Emulation, PCL6 (XL Version 3.0) Emulation, PCL5e/c Emulation, XPS |
||||
| Operating System Supported | Windows 7 (32/64), Windows 8.1 (32/64), Windows 10 (32/64), Windows Server 2008 (32/64), Windows Server 2008 R2,Windows Server 2012, Windows Server 2012 R2, Windows Server 2016, Macintosh OS X 10.8 or later, Linux, Unix, Citrix |
||||
| Printer Fonts | 80 PCL, 137 PostScript 3 Emulation | ||||
| Mobile Printing | AirPrint (iOS), Mopria (Android), Google Cloud Print (optional), Wi-Fi Direct (optional), Konica Minolta Print Service (Android),Konica Minolta Mobile Print (iOS, Android, Windows 10 Mobile) |
||||
| COPIER SPECIFICATIONS | |||||
| Model | 368e | 308e | |||
| Copying Process | Electrostatic laser copy, intermediate | ||||
| Toner Technology | Simitri® HD polymerised toner | ||||
| Copy Speed (A4) | Up to 36 ppm | Up to 30 ppm | |||
| Copy Speed (A3) | Up to 18 ppm | Up to 15 ppm | |||
| First Copy Out Time | 4.5 secs or less | 4.8 secs or less | |||
| Warm-Up Time | 20 secs or less | 18 secs or less | |||
| Copy Resolution | 600 x 600 dpi | ||||
| Gradation | 256 gradations | ||||
| Multiple Copy | 1 – 9,999 | ||||
| Original Format | A6S, B6S, A5-A3 | ||||
| Magnification | 25 – 400% in 0.1% steps; Auto-zooming | ||||
| SCANNER SPECIFICATIONS | |||||
| Model | 368e | 308e | |||
| Scan Speed | with DF-629(Optional) |
1-sided original: 55 ipm @ 600 dpi, 80 ipm @ 300 dpi | |||
| 2-sided original: 26 ipm @ 600 dpi, 37 ipm @ 300 dpi | |||||
| with DF-704(Optional) |
1-sided original: 55 ipm @ 600 dpi, 80 ipm @ 300 dpi | ||||
| 2-sided original: 110 ipm @ 600 dpi, 160 ipm @ 300 dpi | |||||
| Scan Resolution | Max: 600 x 600 dpi | ||||
| Scan Modes | Scan to Email, Scan to PC (SMB), Scan to FTP, Scan to WebDAV, Scan to BOX (HDD), Scan to WSD (Web Service), Scan to DPWS (Device Profile for Web Service), Scan to Scan Server, Scan to USB memory, Network TWAIN scan, Scan to Me, Scan to Home | ||||
| File Formats | JPEG, TIFF, PDF, PDF/A 1a and 1b, compact PDF, encrypted PDF and searchable PDF, XPS, compact XPS, OOXML (pptx, odcx, xlsx), Linearized PDF | ||||
| Scan Destinations | 2,100 (single + group); LDAP, PSDA support | ||||
| FAX SPECIFICATIONS (OPTIONAL) | |||||
| Model | 368e | 308e | |||
| Fax Standard | Super G3 | ||||
| Fax Transmission | Analogue; i-Fax; Colour i-Fax; IP-Fax | ||||
| Fax Resolution | Up to 600 x 600 dpi (ultra-fine) | ||||
| Fax Compression | MH; MR; MMR; JBIG | ||||
| Fax Modem | Up to 33.6 Kbps | ||||
| Fax Destinations | 2,100 (single + group) | ||||
